Amplificador de rango de señal WiFi TP-Link RE350 AC1200
TP-Link RE350 AC1200 Wi-Fi Range Extender |
|
 |
AC1200 Wi-Fi Range ExtenderRE350
- Kills Wi-Fi dead zone with strong Wi-Fi expansion at combined speed of up to 1.2Gbps
- Operates over both the 2.4GHz band(300Mbps) and 5GHz band(867Mbps) for more stable wireless experience
- Gigabit Ethernet port for connecting a wired device to your network at gigabit speed
- High gain external antennas increase the effective Wi-Fi coverage
- Intelligent signal light helps to find the best spot to set up by showing the signal strength
- Works with any Wi-Fi router or wireless access point
Specifications
| HARDWARE FEATURES |
| Plug Type |
EU, UK, US, AU |
| Standards and Protocols |
IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Interface |
1 * 10/100/1000M Ethernet Port (RJ45) |
| Button |
RE (Range Extender) Button, Reset Button, LED Button, Power Button |
| Power Consumption |
11W（max power consumption） |
| Antenna |
2* external |
| Dimensions ( W x D x H ) |
126x75x43mm |
| WIRELESS FEATURES |
| Frequency |
2.4GHz & 5GHz(11ac) |
| Signal Rate |
5GHz:Up to 867Mbps
2.4GHz:Up to 300Mpbs |
| Reception Sensitivity |
5GHz：
11a 6Mbps:-93dBm@10% PER
11a 54Mbps: -76dBm@10% PER
11ac HT20 mcs8: -69dBm@10% PER
11ac HT40 mcs9: -64dBm@10% PER
11ac HT80 mcs9: -61dBm@10% PER
2.4GHz
11g 54M: -78dBm@10% PER
11n HT20 mcs7: -75dBm@10% PER
11n HT40 mcs7: -73dBm@10% PER |
| Wireless Modes |
Range Extender Mode, AP Mode |
| Wireless Functions |
Wireless Statistic
Concurrent Mode boost both 2.4G/5G WiFi band
Access Control
LED Control
Domain Login Function |
| Wireless Security |
64/128-bit WEP
WPA-PSK / WPA2-PSK |
| Transmission Power |
<20dBm(2.4GHz)
<23dBm(5GHz) |
| OTHERS |
| Certification |
CE, FCC, RoHS |
| Package Contents |
AC1200 Wi-Fi Range Extender RE350
RJ-45 Ethernet Cable
Quick Installation Guide |
| System Requirements |
Microsoft® Windows® XP, Vista or Windows 7/8/8.1/10 Mac® OS, NetWare®, UNIX® or Linux. |
| Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
|
|
|
|
|
|
|
